VM1000 MIC PIEZO MEMS ANALOG OMNI
CUI Devices mikrofon CMA-4544PF-W. 20 Hz ~ 20.0 kHz, Circular, Electret Condenser, -44dB ±2dB, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | VM1000 |
| Mfr | Vesper Technologies Inc. |
| Description | MIC PIEZO MEMS ANALOG OMNI |
| Series | Vesper |
| Type | Piezo MEMS |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -38dB ±3dB @ 94dB SPL |
| S/N Ratio | 62dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | - |
| Current - Supply | 165 µA |
| Port Location | Bottom |
| Ratings | IP57 - Dust Protected, Waterproof |
| Termination | Solder Pads |
| Size / Dimension | 0.148" L x 0.116" W (3.76mm x 2.95mm) |
| Height (Max) | 0.051" (1.30mm) |
| Shape | Rectangular |
