SPK0838HT4H-1 RAMIS-B MIC MULTIMODE DIG TOP PT - MIKROFON | MIC
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
SPK0838HT4H-1 RAMIS-B MIC MULTIMODE DIG TOP PT
Mallory Sonalert Products Inc. mikrofon PMOF-9767NP-46DQ. 50 Hz ~ 20.0 kHz, Circular, Electret Condenser, -46dB ±2dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | SPK0838HT4H-1 |
| Mfr | Knowles |
| Description | RAMIS-B MIC MULTIMODE DIG TOP PT |
| Series | SiSonic™ |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -26dB ±3dB @ 94dB SPL |
| S/N Ratio | 64dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | - |
| Current - Supply | 700 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.157" L x 0.118" W (4.00mm x 3.00mm) |
| Height (Max) | 0.043" (1.10mm) |
| Shape | Rectangular |
