PNM-5054L-C3310-R MIC COND ANALOG NC -54DB 6MM D - MIKROFON | MIC
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
PNM-5054L-C3310-R MIC COND ANALOG NC -54DB 6MM D
PUI Audio, Inc. mikrofon POM-3542L-R. 30 Hz ~ 15.0 kHz, Circular, Electret Condenser, -42dB ±3dB, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | PNM-5054L-C3310-R |
| Mfr | PUI Audio, Inc. |
| Description | MIC COND ANALOG NC -54DB 6MM D |
| Series | PNM |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Noise Cancelling |
| Frequency Range | - |
| Sensitivity | -54dB ±3dB |
| S/N Ratio | 56dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | - |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.236" Dia (6.00mm) |
| Height (Max) | 0.205" (5.20mm) |
| Shape | Circular |
