PMO-4015SN-42UQ MIC MAG ANALOG OMNI -42DB 4MM D - MIKROFON | MIC
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
PMO-4015SN-42UQ MIC MAG ANALOG OMNI -42DB 4MM D
PUI Audio, Inc. mikrofon POM-2245L-C33-R. -, Circular, Electret Condenser, -45dB ±4dB, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | PMO-4015SN-42UQ |
| Mfr | Mallory Sonalert Products Inc. |
| Description | MIC MAG ANALOG OMNI -42DB 4MM D |
| Series | PMO |
| Type | Magnetic |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 50 Hz ~ 12.0 kHz |
| Sensitivity | -42dB ±3dB @ 94dB SPL |
| S/N Ratio | 58dB |
| Impedance | 2.2 kOhms |
| Voltage - Rated | 2 V |
| Voltage Range | 1 V ~ 10.0 V |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.157" Dia (4.00mm) |
| Height (Max) | 0.067" (1.70mm) |
| Shape | Circular |
