MT-520 BUZZER PIEZO 18V 51.5MM TH - ALARM, BUZZER, SIREN
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
MT-520 BUZZER PIEZO 18V 51.5MM TH
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MT-520 |
| Mfr | East Electronics |
| Description | BUZZER PIEZO 18V 51.5MM TH |
| Series | MT |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage - Rated | 18 V |
| Voltage Range | 60V |
| Frequency | 2kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 118dB @ 18V, 30cm |
| Current - Supply | - |
| Port Location | Top |
| Operating Temperature | -20°C ~ 105°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 2.028" Dia (51.50mm) |
| Height - Seated (Max) | 0.598" (15.20mm) |
