MMICT4078-00-908 MICROPHONE MEMS ANALOG -38DB - MIKROFON | MIC
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
MMICT4078-00-908 MICROPHONE MEMS ANALOG -38DB
CUI Devices mikrofon CMEJ-0706-42-P. 100 Hz ~ 10.0 kHz, Circular, Electret Condenser, -42dB ±3dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MMICT4078-00-908 |
| Mfr | TDK InvenSense |
| Description | MICROPHONE MEMS ANALOG -38DB |
| Series | MMIC |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | - |
| Frequency Range | 80 Hz ~ 20.0 kHz |
| Sensitivity | -38db ±1dB @ 136dB |
| S/N Ratio | 66dB |
| Impedance | - |
| Voltage - Rated | - |
| Voltage Range | 1.52 V ~ 3.6 V |
| Current - Supply | - |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.132" L x 0.098" W (3.35mm x 2.50mm) |
| Height (Max) | 0.039" (0.98mm) |
| Shape | Rectangular |
