MM042602-15 MICROPHONE MEMS DIGITAL OMNI - MIKROFON | MIC
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
MM042602-15 MICROPHONE MEMS DIGITAL OMNI
BeStar Technologies, Inc. mikrofon HBO0302C-58/1248. 20 Hz ~ 20.0 kHz, Circular, Electret Condenser, -38dB ±3dB, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MM042602-15 |
| Mfr | DB Unlimited |
| Description | MICROPHONE MEMS DIGITAL OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Digital |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -26dB ±1dB |
| S/N Ratio | 65dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | - |
| Current - Supply | 640 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.157" L x 0.118" W (4.00mm x 3.00mm) |
| Height (Max) | 0.043" (1.10mm) |
| Shape | Rectangular |
Bu ürüne ilk yorumu siz yapın!
