FB-FO-23225-000 MIC BOOM ANLG NC -60DB 8.64MM D - MIKROFON | MIC
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
FB-FO-23225-000 MIC BOOM ANLG NC -60DB 8.64MM D
Mallory Sonalert Products Inc. mikrofon PMO-6022SN-42UQ. 20 Hz ~ 16.0 kHz, Circular, Magnetic, -42dB ±3dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | FB-FO-23225-000 |
| Mfr | Knowles |
| Description | MIC BOOM ANLG NC -60DB 8.64MM D |
| Series | FB |
| Type | Boom |
| Output Type | Analog |
| Direction | Noise Cancelling |
| Frequency Range | 300 Hz ~ 4.0 kHz |
| Sensitivity | -60dB ±3dB @ 74dB SPL |
| S/N Ratio | - |
| Impedance | 2.2 kOhms |
| Voltage - Rated | 1.3 V |
| Voltage Range | 1.3 V ~ 10.0 V |
| Current - Supply | 200 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Wire Leads |
| Size / Dimension | 0.340" Dia (8.64mm) |
| Height (Max) | - |
| Shape | Circular |
