FB-BW-30335-000 MIC BOOM ANALOG NC -59DB 8MM D - MIKROFON | MIC
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
FB-BW-30335-000 MIC BOOM ANALOG NC -59DB 8MM D
Soberton Inc. mikrofon EM-6027. 100 Hz ~ 15.0 kHz, Circular, Electret Condenser, -43dB ±5dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | FB-BW-30335-000 |
| Mfr | Knowles |
| Description | MIC BOOM ANALOG NC -59DB 8MM D |
| Series | FB-BW |
| Type | Boom |
| Output Type | Analog |
| Direction | Noise Cancelling |
| Frequency Range | 300 Hz ~ 4.0 kHz |
| Sensitivity | -59dB ±4dB @ 74dB SPL |
| S/N Ratio | - |
| Impedance | 2.2 kOhms |
| Voltage - Rated | 1.3 V |
| Voltage Range | 1.3 V ~ 10.0 V |
| Current - Supply | 300 µA |
| Port Location | Bottom, Top |
| Ratings | IP67 - Dust Tight, Waterproof |
| Termination | Wire Leads |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height (Max) | 0.185" (4.70mm) |
| Shape | Circular |
