EM-6027UN-38 MIC COND ANALOG NC -38DB 6MM D
CUI Devices mikrofon CMC-6027-24L100. 100 Hz ~ 20.0 kHz, Circular, Electret Condenser, -24dB ±3dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | EM-6027UN-38 |
| Mfr | Soberton Inc. |
| Description | MIC COND ANALOG NC -38DB 6MM D |
| Series | EM |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Noise Cancelling |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -38dB ±3dB @ 94dB SPL |
| S/N Ratio | 70dB |
| Impedance | 2.2 kOhms |
| Voltage - Rated | 2 V |
| Voltage Range | 1 V ~ 10.0 V |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | IP50 - Dust Protection |
| Termination | Solder Pads |
| Size / Dimension | 0.236" Dia (6.00mm) |
| Height (Max) | 0.114" (2.90mm) |
| Shape | Circular |
