CS-8412 AUDIO MAGNETIC IND 8-16V TH - ALARM, BUZZER, SIREN
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CS-8412 AUDIO MAGNETIC IND 8-16V TH
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CS-8412 |
| Mfr | CUI Devices |
| Description | AUDIO MAGNETIC IND 8-16V TH |
| Series | CS |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 12 V |
| Voltage Range | 8 ~ 16V |
| Frequency | - |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 77dB @ 12V, 30cm |
| Current - Supply | 30mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 60°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.886" L x 0.657" W (22.50mm x 16.70mm) |
| Height - Seated (Max) | 0.630" (16.00mm) |
