CPT-2207-95-SMT-TR BUZZER, 22.1 MM, 7 MM DEEP, P, 3 - ALARM, BUZZER, SIREN
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CPT-2207-95-SMT-TR BUZZER, 22.1 MM, 7 MM DEEP, P, 3
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CPT-2207-95-SMT-TR |
| Mfr | CUI Devices |
| Description | BUZZER, 22.1 MM, 7 MM DEEP, P, 3 |
| Series | CPT |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage - Rated | 12 V |
| Voltage Range | 30V (Max) |
| Frequency | 4kHz |
| Technology | Piezo |
| Operating Mode | - |
| Duration | - |
| Sound Pressure Level (SPL) | 95dB @ 12V, 10cm |
| Current - Supply | 12mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.870" Dia (22.10mm) |
| Height - Seated (Max) | 0.295" (7.50mm) |
