CPS-3016-105L085 BUZZER, 30.6 MM ROUND, 16 MM DEE - ALARM, BUZZER, SIREN
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CPS-3016-105L085 BUZZER, 30.6 MM ROUND, 16 MM DEE
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CPS-3016-105L085 |
| Mfr | CUI Devices |
| Description | BUZZER, 30.6 MM ROUND, 16 MM DEE |
| Series | CPS |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | DC |
| Voltage - Rated | 12 V |
| Voltage Range | 6 ~ 16V |
| Frequency | 3.25kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 105dB @ 12V, 10cm |
| Current - Supply | 30mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Custom |
| Termination | Wire Leads |
| Size / Dimension | 1.205" Dia (30.60mm) |
| Height - Seated (Max) | 0.650" (16.50mm) |
