CMC-6013-38L100 MICROPHONE COND ANALOG OMNI - MIKROFON | MIC
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
CMC-6013-38L100 MICROPHONE COND ANALOG OMNI
PUI Audio, Inc. mikrofon AOW-4542P-B-R. -, Circular, Electret Condenser, -42dB ±3dB, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CMC-6013-38L100 |
| Mfr | CUI Devices |
| Description | MICROPHONE COND ANALOG OMNI |
| Series | CMC |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 20.0 kHz |
| Sensitivity | -38dB ±3dB @ 94dB SPL |
| S/N Ratio | 60dB |
| Impedance | 2.2 kOhms |
| Voltage - Rated | 2 V |
| Voltage Range | 2 V ~ 10.0 V |
| Current - Supply | 150 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Wire Leads |
| Size / Dimension | 0.236" (5.90mm) Height |
| Height (Max) | 0.059" (1.50mm) |
| Shape | Circular |
