BS2620PH-06-C ELECTRONIC BUZZER, 6 VDC - ALARM, BUZZER, SIREN
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
BS2620PH-06-C ELECTRONIC BUZZER, 6 VDC
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | BS2620PH-06-C |
| Mfr | International Components Corp. |
| Description | ELECTRONIC BUZZER, 6 VDC |
| Series | BS2620PH-06-C |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 6 V |
| Voltage Range | 4 ~ 8V |
| Frequency | 400Hz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 75dB @ 6V, 100cm |
| Current - Supply | 50mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 60°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 1.024" L x 1.024" W (26.00mm x 26.00mm) |
| Height - Seated (Max) | 0.795" (20.20mm) |
