AI-4228-P-C18-R AUDIO PIEZO IND 7-18V PNL MNT - ALARM, BUZZER, SIREN
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
AI-4228-P-C18-R AUDIO PIEZO IND 7-18V PNL MNT
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | AI-4228-P-C18-R |
| Mfr | PUI Audio, Inc. |
| Description | AUDIO PIEZO IND 7-18V PNL MNT |
| Series | AI |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 12 V |
| Voltage Range | 7 ~ 18V |
| Frequency | 2.9kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 108dB @ 12V, 10cm |
| Current - Supply | 16mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 85°C |
| Approval Agency | cUL, UL |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Panel Mount |
| Termination | Screw Terminal, Quick Connect Tab - 0.256" (6.50mm) |
| Size / Dimension | 1.673" Dia (42.50mm) |
| Height - Seated (Max) | 1.299" (33.00mm) |
